ANTHEM PVA 8 AMPLIFIER Product Description
| Brand Name | Anthem | ||
| GENERAL | Inputs | 8-Single-Ended, 1 Relay Trigger (3.5-mm Mono Jack) |
|
| Outputs | 8 Pairs Speaker Binding Posts, 1 Relay Trigger(3.5-mm Mono Jack) |
||
| SWITCHES | Front Panel | Power (On/Off) | |
| Rear Panel |
3 On/Off Modes (Trigger, Manual, Auto) |
||
| POWER OUTPUT | Impedance | # of Channels Driven | |
| 8Ω | 1 | 125 W | |
| All | 90 W | ||
| 4Ω | 1 | 200 W | |
| All | 120 W | ||
| 2Ω | 1 | 300 W | |
| All | – | ||
| OTHER SPECIFICATIONS | HEADROOM | 1.25 db (8 Ω); 2.13 db (4 Ω) |
|
| POWER BANDWIDTH |
10 Hz – 80 kHz (125 W @ 8 Ω) |
||
| FREQUENCY RESPONSE |
20 Hz – 20 kHz (-0.20 db); 5 Hz – 100 kHz (-2.5 db) |
||
| THD + N | <0.002% @ 1 kHz; <0.03% @ 20 kHz (100 W into 8 Ω) |
||
| INPUT SENSITIVITY |
1.12 VRMS for 125 W into 8 Ω |
||
| INPUT IMPEDANCE |
10 kΩ | ||
| DAMPING FACTOR |
200 @ 1 kHz (ref. 8 Ω) |
||
| S/N RATIO |
122 db, A-weighted (ref. 125 W) |
||
| CHANNEL SEPARATION |
>65 db (100 Hz – 10 kHz) |
||
| VOLTAGE GAIN |
29 db | ||
| SLEW RATE |
28 v/µs | ||
| POWER REQUIREMENTS |
1500 W @ maximum power output (8 Ω load) |
||
| DIMENSIONS (H x W x D; heights include feet) |
5-7/8″ (14.9 cm) High x 17-1/4″ (43.8 cm) Wide x 16-3/8″ (42 cm) Deep |
||
| WEIGHT (Unpacked) |
47.5 lb (21.6 kg) | ||
