ANTHEM PVA2 RECEIVER Product Description
Brand Name | Anthem | ||
GENERAL | Inputs | 2-Single-Ended, 1 Relay Trigger (3.5-mm Mono Jack) |
|
Outputs | 2 Pairs Speaker Binding Posts, 1 Relay Trigger(3.5-mm Mono Jack) |
||
SWITCHES | Front Panel | Power (On/Off) | |
Rear Panel |
3 On/Off Modes (Trigger, Manual, Auto) |
||
POWER OUTPUT | Impedance | # of Channels Driven | |
8Ω | 1 | 125 W | |
All | 105 W | ||
4Ω | 1 | 200 W | |
All | 140 W | ||
2Ω | 1 | 300 W | |
All | – | ||
OTHER SPECIFICATIONS | HEADROOM | 1.25 db (8 Ω); 2.13 db (4 Ω) |
|
POWER BANDWIDTH |
10 Hz – 80 kHz (125 W @ 8 Ω) |
||
FREQUENCY RESPONSE |
20 Hz – 20 kHz (-0.20 db); 5 Hz – 100 kHz (-2.5 db) |
||
THD + N | |||
INPUT SENSITIVITY |
<0.002% @ 1 kHz; <0.03% @ 20 kHz (100 W into 8 Ω) |
||
INPUT IMPEDANCE |
10 kΩ | ||
DAMPING FACTOR |
200 @ 1 kHz (ref. 8 Ω) |
||
S/N RATIO |
122 db, A-weighted (ref. 125 W) |
||
CHANNEL SEPARATION |
>65 db (100 Hz – 10 kHz) |
||
VOLTAGE GAIN |
29 db | ||
SLEW RATE |
28 v/µs | ||
POWER REQUIREMENTS |
500 W @ maximum power output (8 Ω load) |
||
DIMENSIONS (H x W x D; heights include feet) |
5-7/8″ (14.9 cm) High x 17-1/4″ (43.8 cm) Wide x 11″ (28 cm) Deep |
||
WEIGHT (Unpacked) |
26 lb (11.8 kg) |
