Benq TK 800M Home Entertainment Projector for Sports Fans with 4K HDR Product Description
| Brand | BenQ |
|
Main Specifications |
|
| Resolution | 4K UHD (3840 x 2160) |
| Brightness (ANSI lumens) | 3000 ANSI Lumens |
| Contrast Ratio (FOFO) | 10,000:1 |
| Speaker | 5W x 1 |
|
All Specifications |
|
| Display | |
| Projection System | DLP |
| Resolution | 4K UHD (3840 x 2160) |
| Resolution Support | VGA (640 x 480) to 4K UHD (3840 x 2160) |
| Brightness (ANSI lumens) | 3000 ANSI Lumens |
| Contrast Ratio (FOFO) | 10,000:1 |
| Display Color | 30 Bits (1,07 billion colors) |
| Native Aspect Ratio | Native 16:9 (6 aspect ratio selectable) |
| Light Source | Lamp |
|
Light Source Wattage |
240W |
| Light Source Life | Normal 4,000 hoursSmartEco 8,000 hours
Economic 10,000 hours LampSave 15,000 hours |
| Optical | |
| Throw Ratio | 1.50 – 1.65 (100″ @ 3.32 m) |
| Zoom Ratio | 1.1x |
| Keystone Adjustment | 1D, Vertical ± 40 degrees |
| Projection Offset | 110% |
| Clear Image Size (Diagonal) | 60″~200″ / 300″ |
| Image Size | 30″ ~ 300″ |
| Horizontal Frequency | 15K – 102KHz |
| Vertical Scan Rate | 23 – 120Hz |
| Picture | |
| Color Wheel Segment | 4-Segment (RGBW) |
|
Rec.709 Coverage |
96% |
| Audio |
|
|
Speaker |
5W x 1 |
| Interface | |
| HDMI | x2 (HDMI 2.0b & HDCP 2.2) |
| USB Type A | x1 (5V/2.5A power supply)
x1 (USB 2.0 Media Reader/ Firmware upgrade) x1 (USB 3.0 Media Reader/ Firmware upgrade) |
| USB Type mini B | x1 Firmware upgrade |
| Audio out (3.5mm Mini Jack) | x1 |
| LAN (RJ45) | x1 RJ-45 LAN input jack (10/100M) |
| RS232 (DB-9pin) | x1 RS232 In (D-sub 9pin, male) |
| DC 12V Trigger (3.5mm Jack) | x1 (3.5mm Jack) |
| IR Receiver | x2 (Front/Top) |
| Wired Remote in (3.5mm Mini Jack) |
x1 |
|
Special Feature
|
|
| HDR |
Yes (HDR10, HLG) |
|
Motion Enhancer (MEMC) |
Yes |
|
ISF Night/ Day |
Yes |
|
LAN control |
Yes |
| CinemaMaster Video + | Yes (4K Motion Enhancer, 4K Pixel Enhancer, Color Enhancer, Flesh Tone) |
| Compatibility | |
| HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Environment | |
| Power Supply | VAC 100 ~ 240 (50/60Hz) |
|
Typical Power Consumption |
Max 385W, Normal 330W, Eco 250W |
| Standby Power Consumption | 0.5W Max. at 100 ~ 240VAC |
|
Acoustic Noise (Typ./Eco.) |
33/29 dBA |
| Operating Temperature | 0~40℃ |
|
Dimension and Weight |
|
| Dimensions (W x H x D)(mm) | 353 x 135 x 272 (mm) |
| Net Weight (Kg/ lbs ) | 4.2 kg / 9.2 lbs |
|
Accessories (Standard)
|
|
| Remote Control w/ Battery | x 1 (RCV015) w/ AAA Battery x 2 |
|
Power Cord (by region)
|
x 1 (3m) |
|
User Manual CD
|
Yes |
|
Quick Start Guide
|
Yes |
|
Warranty Card (by region)
|
Yes |
|
Accessories (Optional)
|
|
| Carry Bag | Optional Carry Bag (5J.J4N09.00) |
| Spare Lamp Kit | Optional |
|
Universal Ceiling Mount
|
Optional |
|
3D Glasses
|
Optional DLP 3D Glasses (GDG5) |
| QCast Mirror dongle |
Optional |
| Wireless FHD Kit | Optional |
| OSD | Optional DLP 3D Glasses (GDG5) |
|
OSD Language |
Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages) |
