Epson LS-10000 4K HT Projector Product Description
| Projection System |
3LCD Reflective 3-Chip technology |
| Projection Method |
Front / rear / ceiling mount |
| Product Color |
Black |
| Driving Method |
Epson Poly-silicon TFT Active Matrix, 0.74-inch wide panel Reflective HTPS |
| Projected Output |
HD, 2D, 3D, 1080p |
| Pixel Number |
2,073,600 dots (1920 x 1080) x 3 |
| Color Brightness (Color Light Ouput) |
1500 lumens1 |
| White Brightness (White Light Output) |
1500 lumens1 |
| Aspect Ratio |
16:9 widescreen (4:3 resize) Compatible with 4:3 and 2.35:1 video formats with Normal, Full or Zoom Modes |
| Native Resolution |
1080p (1920 x 1080) |
| Resize | 16:10, 4:3 |
| Laser Type |
Laser Diode 41.9 mW (Output) |
| Light Source Life |
Up to 30,000 hours (ECO Mode)2 |
| Throw Ratio Range |
|
| Size (projected distance) |
100″ diagonal (wide: 9.3′ €“ tele: 19.8′) |
| Keystone Correction |
±30 degrees |
| Contrast Ratio |
Absolute Black (Full White 1500 lumens / Full Black 0 lumens) |
| Color Reproduction |
Up to 1.07 billion colors |
| Color Processing |
10 bit (Partial 12 bit) |
| Type | Powered Optical zoom/ Powered focus |
| F-number | 2.5 €“ 3.7 |
| Focal Length |
21.3 mm €“ 44.7 mm |
| Zoom Ratio |
1.0 €“ 2.1 |
| Lens Shift |
Vertical: 90% max (up and down with horz. centered) Horizontal: 40% max (left and right with vertical centered) |
| Lens Cover |
Powered, Slide Lens Shutter |
| Lens Position |
the following 3 items are saved in memory: Lens Shift Position / Zoom Position / Focus Position |
| Memory Positions |
10 (Memory 1 €“ 10) |
| Picture-in-Picture | |
| Display Performance |
1920 x 1080 native 1080p; HD, 2D, 3D, 2D to 3D conversion |
| Color Modes |
Dynamic, Living room, Natural, THX, Cinema, B&W Cinema, Adobe RGB, Digital Cinema, 3D Dynamic, 3D Cinema, 3D THX |
| Lens Iris |
Fine adjustments |
| Super Resolution |
4K Enhancement Off / 1 / 2 / 3 / 4 / 5 / 4K-1 / 4K-2 / 4K-3 / 4K-4 / 4K-5 |
| Deinterlacing | Film / Auto, Video, Off |
| Frame Interpolation |
Off / Low / Normal /High (2D and 3D Mode) |
| Pull Down |
(1080/24p) 10:10 pull down |
| Epson Super White |
Controlled automatically adjusting to HDMI source (Available at Natural / THX / Cinema / B&W Cinema / 3D Cinema / 3D THX, User selectable On/Off on OSD) |
| Input Signal |
HDMI 480i/576i/480p/576p/720p/1080i/1080p/ 4K x 2K |
| Terminal Outputs |
(2 x) configurable as Screen Power or Anamorphic Lens – Trigger On/Off (3.5 mm mini-stereo jack) each – 12 VDC 200 mA (max.) |
| Computer Compatibility |
PC, Mac® |
| Interfaces | HDMI x 2 RS-232c x 1 RCA (composite) x 1 RCA (component) x 3 VGA D-sub 15 pin (computer input) x 1 Wired LAN (RJ45, 100 Mbps) for command and Control only x 1 |
| Operating Temperature |
41° to 95° F (5° to 35° C) |
| Power Supply Voltage |
100 €“ 240 VAC ±10% , 50/60 Hz |
| Power Consumption |
ECO mode: Laser on 267 W Standby mode: 0.29 W |
| Fan Noise |
19 dB €“ 28 dB (4K Enhancement: Off) |
| Security | Kensington Security Lock Port |
| Including feet |
21.65″ x 21.77″ x 8.85″ (W x D x H) |
| Weight | 39.7 lbs |
| Features | Front and rear |
| Operating Angle |
Front: Right / Left: ±30 degrees Upper / Lower: ±30 degrees Rear: Right / Left: ±30 degrees Upper / Lower: 0 €“ +60 degrees |
| Operating Distance |
19.7 ft |
| Power Button Lock |
Hinders projector from being turned on without parental supervision |
